233Service Manual – CS7010™ 34 - Scrub System
supporting the deck lift arm assembly and scrub deck, and remove the two screws, washers, bushings,
and ange bearings holding the deck lift arm assembly and attached scrub deck to the machine frame.
6. Remove the bow-tie cotter pin, washers and clevis pin holding the scrub deck actuator to the deck lift
arm assembly.
7. Jack the machine up as necessary to get enough clearance to remove the Scrub Deck, then support the
machine with jack stands.
CAUTION: Never work under a machine without safety stands or blocks to support the machine.
When jacking the machine, do so at the designated Tie Down/Jacking Locations.
8. Slide the scrub deck and attached deck lift arm assembly out from under the machine.
9. Reinstall the Scrub Deck by following the above steps in reverse order and the following notes:
• Make sure you reconnect the Scrub Motors to the correct Electrical Connectors in the wire harness
• Make sure the two ange bearings are installed in the machine frame through holes, and that the
bushings and washers are installed correctly before installing the two M12 screws.
• You may nd it easier to use a tapered punch or other suitable tool to align the bushings, ange
bearings and deck lift arm assembly with the through holes in the frame before you install the M12
screws.
