27Service Manual – CS7010™ 03 - General Information
Ref Visual Inspection Items OK
Not
OK
Defect Codes
(circle)
29 Scrub deck housing and door skirts C D W
30 Solution system pumps and solenoid valves as many as six pumps C L W
31 Solution tank, delivery hoses and lter clean lter screen C L M
32 Dust control system impeller motor C L D
33 Recovery tank screen and oat clean screen B C
34 Recovery tank debris basket clean C
35 Recovery tank cover gasket D L W
36 Recovery tank drain hose and cap C D L M
37 Squeegee pick-up hose back ush C L
38 Squeegee tool and blades clean and rotate C D W
39 Squeegee casters, adjustment knob and linkage grease C W
40 Battery/Batteries clean and water C
41 Engine, oil level, hoses and belts (LP and diesel only) C D L
42 Engine air cleaner inner and outer elements (LP and diesel only)
check service indicator
C L
43 Engine coolant level (LP and diesel only) ll at reservoir C L
44 Radiator and oil cooler core blockage (LP and diesel only) clean C D L
45 Fuel tank, lter and lines (diesel only) C L W
46 LP tank, hoses and ttings (LP only) L W
47 LP fuel lter service life 1500 hrs. C
48 LP fuel regulator, lock off valve and hoses L
49 Diesel glow plug function light hard starting
50 Diesel fuel tank strainer yearly C
51 Brake linkage and parking brake pedal A B
52 Circuit breaker panel D M W
53 Front tires (check lug nut torque 100 ft-lbs., 135 Nm) A
54 Rear drive wheel motor, steering system grease pinion gear D L W
55 Front and rear tires tread wear C W
56 Debris hopper clean C
57 Recovery hose and pick-up screen back ush/clean C
58 DustGuard™ spray nozzles and strainers clean C L W
Comments:
Work Completed By: Acknowledged By:
Service Technician Signature Date Customer Signature Date
