307Service Manual – CS7010™ 52 - Hopper System
34. Raise the hopper and check the position of the
“UP” Hydraulic Hose. The “UP” Hydraulic Hose
should be positioned as shown so it doesn’t
contact the hopper when the hopper is down.
35. Loosen and reposition the “UP” Hydraulic Hose
as necessary to avoid any abrasion or damage.
36. Reinstall the reservoir guard.
37. Check the oil level in the reservoir. It should
be at the MIN line when the cylinder is fully
extended (hopper is raised).
“UP”
Hydraulic
Hose
To Next Page
