to enable faster changes for larger values. This function
also applies to the [
▼
] key.
4.4.14 Left [
◀
] and Right [
▶
] Keys
When editing a parameter, use the [
◀
] key to move the
cursor 1 digit to the left, and the [
▶
] key to move the
cursor 1 digit to the right. Both keys have wrap-around
navigation: When the cursor is at the 1
st
digit (on the far
right), pressing the [
▶
] key moves it to the last digit (on
the far left). This function also applies to the [
◀
] key.
When the [
◀
] key is pressed while navigating the menu
system, the menu screen moves to the previous subgroup
or group. This function also applies to the [
▶
] key.
4.5 LCP-specic Parameters
LCP-specic parameters are dened for both the ISD 510 Servo Drive LCP (see chapter 4.5.1 ISD 510 Servo Drive-specic LCP
Parameters) and for the SAB LCP (see chapter 4.5.2 SAB-specic LCP Parameters).
4.5.1 ISD 510 Servo Drive-specic LCP Parameters
Parameter number Name Unit Description
00-20 Display line 1.1 small – Select a variable for display in line 1, left position.
00-21 Display line 1.2 small – Select a variable for display in line 1, middle position.
00-22 Display line 1.3 small – Select a variable for display in line 3, right position.
00-23 Display line 2 large – Select a variable for display in line 2.
00-24 Display line 3 large – Select a variable for display in line 3.
00-33 Unit for position
readout
– Selects the desired unit for position readout.
00-34 Unit for velocity
readout
– Selects the desired unit for velocity readout.
00-35 Unit for acceleration
readout
– Selects the desired unit for acceleration readout.
52-02 Hand On mode – Gets or sets the Hand On mode of operation: Position,
Velocity, Jog, or Inertia measurement.
52-03 Hand On state – Sets the Hand On state: enabled or disabled.
52-11 Positioning type – Gets or sets the positioning type (absolute or relative) when
running in Hand On mode for positioning.
52-63 Start Inertia
Measurement
– Starts the inertia measurement procedure.
52-64 Inertia Measurement
Result
kg m² Shows the inertia measurement result.
52-70 Jog Mode Control – Enables or disables Jog in Hand On mode.
52-71 Jog speed User units, as dened in
parameter group 00-3*.
Contains the commanded jog speed in user units (factor
group has been applied).
Table 4.11 ISD 510 Servo Drive-specic LCP Parameters
Local Control Panel (LCP) O... Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 107
4 4

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
