Danfoss VLT series Programming Guide

DD_CamScaling_ISD51x
AXIS_REF_ISD51x
BOOLExecute
Slave
DINTMasterScalingNumerator
DINTMasterScalingDenominator
DINTSlaveScalingNumerator
DINTSlaveScalingDenominator
DoneBOOL
BusyBOOL
ErrorBOOL
ErrorInfoDD_ERROR_ISD51x
130BE262.10
Illustration 6.74 DD_CamScaling_ISD51x
Variable
name
Data type Default
value
Description
VAR_IN_OUT
Slave AXIS_REF_ISD51x Reference to the slave axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Starts the parameter
transfer to the servo drive
at rising edge.
MasterSca-
lingNumerato
r
DINT 1 Numerator for the CAM
master scaling. From the
slave point of view, the
master overall prole is
multiplied by this factor.
MasterSca-
lingDenomina
tor
DINT 1 Denominator for the CAM
master scaling. From the
slave point of view, the
master overall prole is
divided by this factor.
SlaveScaling-
Numerator
DINT 1 Numerator for the CAM
slave scaling. The overall
slave prole is multiplied
by this factor.
SlaveScaling-
Denominator
DINT 1 Denominator for the CAM
slave scaling. The overall
slave prole is divided by
this factor.
VAR_OUTPUT
Done BOOL The parameters have been
set.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Table 6.56 DD_CamScaling_ISD51x
6.5.6.4 DD_SetFollowSegment_ISD51x
This function block is used for advanced CAMs only. It
instructs the node to use the specied segment when it is
passed.
DD_SetFollowSegment_ISD51x
Axis
ExecuteBOOL
AXIS_REF-
_ISD51x
BOOL
Done
BOOL
Busy
BOOL
DD_ERROR_ISD51x
ErrorInfo
Error
NodeIDUINT
SegmentID
UINT
130BE957.10
Illustration 6.75 DD_SetFollowSegment_ISD51x
Variable
name
Data type Default
value
Description
VAR_IN_OUT
Axis AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Sends the switching
command to enable/
disable the node noti-
cation at rising edge.
NodeID UINT 0 ID of the node where the
following segment should
be switched.
SegmentID UINT 0 ID of the segment that
should be used from now
on after the node with
NodeID.
VAR_OUTPUT
Done BOOL The command has been
set.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Table 6.57 DD_SetFollowSegment_ISD51x
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 215
6
6
