238 Configuring Device Information
www.dell.com | support.dell.com
GARP Leave Timer (10 - 2147483640
) — Time lapse, in milliseconds, that the device waits before
leaving its GARP state. Leave time is activated by a Leave All Time message sent/received, and
cancelled by the Join message received. Leave time must be greater than or equal to three times the
join time. The possible field value is 0-2147483640. The default value is 600 msec.
GARP Leave All Timer (10 - 2147483640)
— Time lapse, in milliseconds, that all devices wait
before leaving the GARP state. The leave all time must be greater than the leave time
.
The possible
field value is 0-2147483640. The default value is 10000 msec.
Defining GARP Timers
1
Open the
GARP Timers
page.
2
Complete the fields.
3
Click
Apply Changes
.
The GARP parameters are saved to the device.
Copying Parameters in the GARP Timers Table
1
Open the
GARP Timers
page.
2
Click
Show All
.
The
GARP Timers Table
opens.
3
Select the interface type in the
Copy Parameters from
field.
4
Select an interface in either the
Port
or
LAG
drop-down menu.
5
The definitions for this interface is copied to the selected interfaces. See step 6.
6
Select the
Copy to
check box to define the interfaces to which the GARP timer definitions
are copied, or click
Select All
to copy the definitions to all ports or LAGs.
7
Click
Apply Changes
.
The parameters are copied to the selected port ports or LAGs in the
GARP Timers Table
, and
the device is updated.
Defining GARP Timers Using CLI Commands
This table summarizes the equivalent CLI commands for defining GARP timers as displayed in the
GARP Timers
page.
Table 7-59. GARP Timer CLI Commands
CLI Command Description
garp timer {join | leave | leaveall}
timer_value
Adjusts the GARP application join,
leave, and leaveall GARP timer values.
