Dell PowerConnect 5324 User Manual

Configuring Device Information 243
The following is an example of the CLI commands:
show spanning-tree [ethernet
interface | port-channel port-
channel-number]
Displays spanning tree configuration
identifier.
show spanning-tree [detail] [active
| blockedports]
Displays spanning tree configuration
information - detailed information or
active ports or blocked ports.
Table 7-60. STP Global Parameter CLI Commands
CLI Command Description
console(config)# spanning-tree
console(config)# spanning-tree mode rstp
console(config)# spanning-tree priority 12288
console(config)# spanning-tree hello-time 5
console(config)# spanning-tree max-age 15
console(config)# spanning-tree forward-time 25
console(config)# exit
console# show spanning-tree
Spanning tree enabled mode RSTP
Default port cost method: short
Root ID Priority 12288
Address 00:e8:00:b4:c0:00
This switch is the root
Hello Time 5 sec Max Age 15 sec Forward Delay 25 sec
Number of topology changes 5 last change occurred 00:05:28 ago
Times: hold 1, topology change 40, notification 5
hello 5, max age 15, forward delay 25

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
