262 Configuring Device Information
www.dell.com | support.dell.com
Ingress Filtering — Enables or disables Ingress filtering on the port. Ingress filtering discards
packets that are destined to VLANs of which the specific LAG is not a member.
Current Reserve VLAN — The VLAN currently designated by the system as the reserved VLAN.
Reserve VLAN for Internal Use — The VLAN selected by the user to be the reserved VLAN if not
in use by the system.
Assigning Port Settings
1 Open the VLAN Port Settings page.
2 Select the port to which settings need to be assigned from the Port drop-down menu.
3 Complete the remaining fields on the page
4 Click Apply Changes .
The VLAN port settings are defined, and the device is updated.
Displaying the VLAN Port Table
1 Open the VLAN Port Settings page.
2 Click Show All.
The VLAN Port Table opens.
Assigning Ports to VLAN Groups Using CLI Commands
The following table summarizes the equivalent CLI commands for assigning ports to VLAN
groups.
Table 7-67. VLAN Port CLI Commands
CLI Command Description
switchport mode {access | trunk
| general}
Configures a port VLAN membership mode.
switchport trunk native vlan
vlan-id
Defines the port as a member of the specified
VLAN, and the VLAN ID as the "port default
VLAN ID (PVID)".
switchport general pvid vlan-id Configure the Port VLAN ID (PVID) when the
interface is in general mode.
switchport general allowed vlan
add vlan-list [tagged |
untagged]
Adds or removes VLANs from a general port.
switchport general acceptable-
frame-types tagged-only
Discards untagged packets at ingress.
switchport general ingress-
filtering disable
Disables port ingress filtering.

Dell PowerConnect 5324 Specifications

General

Switching Capacity	48 Gbps
VLAN Support	Yes
Rack Mountable	Yes
Device Type	Switch
MAC Address Table Size	8K entries
RAM	64 MB
Flash Memory	8 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Jumbo Frame Support	Yes
Ports	24 x 10/100/1000 + 2 x SFP
Management	Web-based, SNMP, CLI
Enclosure Type	Rack-mountable
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, 2, 3
Features	Flow control, auto-negotiation, port mirroring, Quality of Service (QoS)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 °C to 45 °C
Storage Temperature	-20 °C to 70 °C
Humidity	5% to 95% (non-condensing)
Layer	Layer 2
