FOR-A FA-9600 Series - Page 122

122
Item
Default
Setting
Description
FS1
Converter
Source
Select
Synchronizer
1
Synchronizer 1
Synchronizer 2
Selects a Converter1 input source.
Format
Convert
Follow Input
Follow Input
Manual
Specifies the converter output format.
Follow Input: Converter input signal format
Manual: Signal format specified below.
◆ I/P Convert
Item
Default
Setting
Description
Motion
Sense
Adaptive
Adaptive
Field
Frame
(Odd 1st)
Frame
(Even 1st)
Field: Generates a progressive image from one field of
an interlaced image. The created image has no motion
artifacts, but vertical resolution will be reduced.
Adaptive: Detects whether there is motion or no motion
in the scene, and generates an optimal progressive
image.
Frame(Odd 1st): Generates a progressive image from
two fields (odd and even) of an interlaced image.
Suitable for progressive segmented frame input shot in
progressive format.
Frame(Even 1st): Generates a progressive image from
two fields (even and odd) of and interlaced image.
The following parameters are enabled when Format Convert is set to Manual.
Refer to Sec. 5-20-1. “Available Conversions on Converter 1 (FS1)” and Sec. 5-20-2.
“Available Conversions on Converter 2 (FS2)” for more details.
◆ Output Format
Item
Default
Setting
Description
Standard
1080
SD
720
1080
2160
Specifies the vertical image
resolution. (2160 available only
on FS1 in Simultaneous 4K/HD
or 3D-LUT mode with FA-964K.)
Horizontal
-
-
(Not used)
Frame
Rate
59.94i
60p, 59.94p, 50p, 48p, 47.95p
30p, 29.97p, 25p, 24p, 23.98p
60i, 59.94i, 50i
24PsF, 23.98PsF,
30PsF, 29.97PsF, 25PsF
Specifies the frame/field rate.
Level
Level-A
Level-A
Level-B
Selects the SDI mapping level.
Division
(UHD)
(FA-964K)
2SI
SQD
2SI
Selects the SDI image division
method when 2160 is selected
under Standard.
