User 07: SDR 2.2 BT.709
User 08: S-Log3
User 09: 01_Canon Log 2
User 10: 01_Canon Log 3
S-Log3 Live HDR
SDR(SONY)
changed by editing files in the Web GUI.
(See Sec. 13-4. “Data.”)
These settings are shared by both input
and output gamma curve settings.
S-Log3 Live HDR and SDR(SONY)
require FA-96AHDR2 option.
If SDR(SONY) is selected, choose a
curve by pressing the SR-Live Detail
button.
Rec. ITU-R BT.709
Rec. ITU-R BT.2020
User 01: S-Gamut/Gamut3
User 02: User2
User 03: User3
User 04: User4
User 05: User5
Selects a color space for input.
User 01-05 Gamut settings are stored in
files and these names and content can
be changed by editing files in the Web
GUI. (See Sec. 13-4. “Data.”)
These settings are shared by both input
and output gamut curve settings.
Selects a gamma curve for output.
Selects the color space for output
◆ SDR(SONY) Gamma (FA-96AHDR2 required)
If SDR(SONY) is selected for Gamma Curve, press the Detail button to display the dialog box.
◆ OOTF (Y)
OOTF is applied as a display gamma (see ITU-R BT.2390) and effective when converting a
signal to or from an HLG signal (with BT.2100 gamma curve).
Change OOTF(Input) or Inverse OOTF(Output) to Enable, then click Detail under OOTF for
HLG Detail to set the following parameters
See Sec. 5-6-1. "About OOTF Related Parameters" for details on settings
Sets the maximum luminance
peak for Display Light.
Sets the minimum luminance peak
for Display Light.
Refer to Sec. 4-1. “Color Processor Setting Example” for setting details.
To Next Page
