Disable: Disables delay adjustment.
Same as FS1:
Adjusts video and audio timings by adding
the converter delay to embedded audio for
the SDI output. The additional delay
amount is displayed to the right.
Displays the channel number and status of audio source
automatically assigned to Dolby E Alignment. (1
st
system)
Pressing the button adjusts the audio delay.
Displays the channel number and status of audio source
automatically assigned to Dolby E Alignment. (2
nd
system)
Pressing the button adjusts the audio delay.
See Sec. 6-24. “Dolby E Alignment” for more details.
To set Standard AES, optional FA-96AES-UBL and FA-96AES-UBLC AES audio, click AES.
To set audio of the option card installed on Slot B (FA-96ANA-AUD or FA-96MADI), click
Option B.
AES Audio Setting Analog or MADI Audio Setting
Additional Audio
Delay(AES)
Disable
Same as FS1
Same as FS2
Standard AES audio output setting
Disable: Disables delay adjustment,
Same as FS1:
Same as FS2:
Adjusts video and audio timings by
adding the FS1 or FS2 converter
delay to the audio output.
