FOR-A FA-9600 Series User Manual

193
Category
Target
Item
Default
Value
Description
Required
Ref.
OOTF OUT Display Peak
1000
100 - 10000
OUTPUT SIDE Peak (Max. Brightness)
(in 100 increments)
OOTF OUT Display Black
0
0 - 100
OUTPUT SIDE Black (Min. Brightness)
(in 10 increments)
OOTF RGB
0
0
1
0: Adjustment
1: SR-Live
FA-
96AHDR2
5-6
System Gamma
1
0
1
2
3
4
0-4: 1.1 to 1.5
FA-
96AHDR2
OOTF FOR SR-Live
0
0
1
2
0: Disable
1: Inverse OOTF
2: OOTF
FA-
96AHDR2
SDR(SONY)
0
0
1
2
3
4
5
6
7
8
9
10
0-6: STANDARD1-7
7-10: HYPER1-4
FA-
96AHDR2
Dynamic Range Gain
0
-2400 - 2400
Setting value is one-hundredth of input value.
Ex) 1230 => 12.30dB
5-18
SDR Gain
0
0 - 2400
Setting value is one-hundredth of input value.
Ex) 1230 => 12.30dB
DRC 3DLUT
0
1
2
3
4
5
6
7
8
9
10
11
12
13
3D-LUT data
1 - 10: User 01 - User 10
11 - 13:(FA-96AHDR2 required)
(FA-
96AHDR2)
5-7
IO Range
0
0
1
2
3
Input and output signal ranges for 3D-LUT
0: Narrow >> Narrow
1: SDI >> SDI
2: Narrow >> SDI
3: SDI >> Narrow
(FA-96
AHDR2)
5-7
COM
Simul Mode
0
0
1
0: Disable
1: Enable
5-18
Color Space CONV
FS1/FS2
In Color Space
0
0
1
2
3
4
5
6
0: Rec. ITU-R BT.709
1: Rec. ITU-R BT.2020
2: User 1
3: User 2
4: User 3
5: User 4
6: User 5
5-4
Out Color Space
0
0
1
2
3
4
5
6
0: Rec. ITU-R BT.709
1: Rec. ITU-R BT.2020
2: User 1
3: User 2
4: User 3
5: User 4
6: User 5
