FOR-A FA-9600 Series User Manual

206
Category
Target
Item
Default
Value
Description
Required
Ref.
MAP Ch20
19
MAP Ch21
20
MAP Ch22
21
MAP Ch23
22
MAP Ch24
23
MAP Ch25
24
MAP Ch26
25
MAP Ch27
26
MAP Ch28
27
MAP Ch29
28
MAP Ch30
29
MAP Ch31
30
MAP Ch32
31
Master Gain
0
-200 - 200
Setting value is one-tenth of input value.
Ex) 123 => 12.3dB
6-21
Gain Ch1
|
Gain Ch32
0
-400 - 400
Setting value is one-tenth of input value.
Total gain for each channel =
(Master Gain value) + (Channel Gain value)
Output Conv. Delay
1
0
1
2
0: Disable
1: Same as FS1
2: Same as FS2
6-25
Output Mode
1
0
1
2
3
0: 56ch Mode
1: 64ch Mode
2: Input Through
3: Output Disable
6-15
Output Select Ch.33-64
0
0
1
2
3
4
5
0: Silence
1: MADI In Ch.1-32
2: MADI In Ch.9-40
3: MADI In Ch.17-48
4: MADI In Ch.25-56
5: MADI In Ch.33-64
FA-96DIN4CBL
SlotD
LtcOutSrc
0
0
1
0: Generator 1
1: Generator 2
FA-96
DIN4- CBL
5-35
