FOR-A FA-9600 Series User Manual

211
Element
Contents
Note
Identifier
Description
Minimum
Maximum
Access
Format
Enumeration
Factor
Default
Type
Node
fs-1 or fs-2
Only fs-1 in 3D-LUT mode.
Node
colorCorrection
Unavailable in 3D-LUT mode.
Node
differential
Differential
Node
white
Parameter
r-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
White Level(R-Y)
Parameter
g-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
White Level(G-Y)
Parameter
b-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
White Level(B-Y)
Node
black
Parameter
r-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
Black Level(R-Y)
Parameter
g-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
Black Level(G-Y)
Parameter
b-y
0
2000
Read/Write(3)
%.1f %%
10
1000
Integer(1)
Black Level(B-Y)
Node
drcAndCrc
Parameter
drConvert
Dynamic Range Convtert
Read/Write(3)
0: Bypass
1: Operate
Boolean(4)
Parameter
inputGamma
Read/Write(3)
0: ~Bypass
1-10: User 1-10
11: S-Log3 Live HDR
12: ~HLG Live
13: SDR(SONY)
Integer(1)
Unavailable in 3D-LUT mode.
~Bypass: Hidden
~HLG Live: Hidden
The following settings require
FA-96AHDR2.
S-Log3 Live HDR
SDR(SONY)
Parameter
inputColor
Read/Write(3)
0: BT.709
1: BT.2020
2-6: User 1-5
Integer(1)
Unavailable in 3D-LUT mode.
Parameter
outputGamma
Read/Write(3)
0: ~Bypass
1-10: User 1-10
11: S-Log3 Live HDR
12: ~HLG Live
13: SDR(SONY)
Integer(1)
Unavailable in 3D-LUT mode.
~Bypass: Hidden
~HLG Live: Hidden
The following settings require
FA-96AHDR2.
S-Log3 Live HDR
SDR(SONY)
Parameter
outputColor
Read/Write(3)
0: BT.709
1: BT.2020
2-6: User 1-5
Integer(1)
Unavailable in 3D-LUT mode.
Parameter
lut3d
3D-LUT
Read/Write(3)
0: ~Linear
1-10: User 1-10
11: HLGLive >> 709
12: 709 >> HLGLive
13: SL3Live >> HLG
Integer(1)
Availabe in 3D-LUT mode
~Linear: Hidden
The following settings require
FA-96AHDR2.
HLGLive >> 709,
709 >> HLGLive and
SL3Live >> HLG
Parameter
ioRange
In/Out Range
Read/Write(3)
0: Narrow >> Narrow
1: SDI >> SDI
2: Narrow >> SDI
3: SDI >> Narrow
Integer(1)
3D-LUT mode only
Parameter
drGain
Dynamic Range Gain
-2400
2400
Read/Write(3)
%.2f dB
100
0
Integer(1)
Unavailable in 3D-LUT mode.
Parameter
sdrGain
SDR Gain
0
2400
Read/Write(3)
%.2f dB
100
0
Integer(1)
Unavailable in 3D-LUT mode.
