FOR-A FA-9600 Series User Manual

61
NOTE
If input and output signals are the same format, or converting signals between 1080 and 4K, only
simple resolution conversion is performed, but scaling are not performed because higher priority
is given to minimizing process delay. In such cases, you still need to perform scaling or
positioning, enable this menu. Note that enabling this menu requires one frame delay.
◆ RESIZE 2 (Available if Scaling is set to Enable)
Item
Default
Setting
Description
Horizontal Size
100.0%
50.0% to 150.0%
Selects the horizontal image size
ratio after conversion.
Vertical Size
100.0%
50.0% to 150.0%
Selects the vertical image size ratio
after conversion.
Horizontal
Position
0 Pixel
See the table below.
Selects the horizontal image
position after conversion.
Vertical Position
0 Line
See the table below.
Selects the vertical image position
after conversion.
◆ RESIZE 3 (Available if Scaling is set to Enable)
Cropping Left
0 Pixel
See the table below.
Crops the image from the left side.
Cropping Right
0 Pixel
Crops the image from the right side.
Cropping Top
0 Line
See the table below.
Crops the image from the top.
Cropping Bottom
0 Line
Crops the image from the bottom.
Video signal
Horizontal Position
(per 2-pixel)
Vertical Position
Cropping Left
Cropping Right
(per 2-pixel)
Cropping Top
Cropping Bottom
2160p
-1920 to 1920
-1080 to 1080
0-1918
0-1079
1080i/p
-960 to 960
-540 to 540
0-958
0-539
720p
-640 to 640
-360 to 360
0-638
0-359
525i (NTSC)
-360 to 360
-243 to 243
0-358
0-243
625i (PAL)
-360 to 360
-288 to 288
0-358
0-287
