SECTION 6 - GENERAL MECHANICAL OVERHAUL
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Figure 72
60521
Once assembly is complete, block the cylinder liners (1) at the
crankcase (2) with stud bolts 99360703 (3).
Crankshaft measurements
Figure 73
38.700
39.000
47.95
48.00
131.122
131.147
3.380
3.430
47.785
47.800
47.785
47.800
95.970
96.000
38.700
39.000
3.380
3.430
99.970
100.000
A
A
A
A
X Y
Main journals upper bearing shells
Crankshaft
Main bearing lower half bearings
60521
A = 3.115 - 3.146
