SECTION 2 - OPERATING DIAGRAMS
11
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
LUBRICATION
The engine is lubricated by gear pump driven via gears by the crankshaft.
A heat exchanger regulates the temperature of the lubricating oil.
It houses the oil filter, indicator sensors and safety valves.
Figure 10
224069
A Descending oil - B Oil at pressure
