190512
Figure 7
Pressure sensor inside engine crankcase
The crankshaft pressure sensor is used to measure the pres-
sure inside the engine.
10
SECTION 3 - ELECTRIC EQUIPMENT
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Pin Description ECU pin
1 Power supply EDC17, pin A/32
2 Ground EDC17, pin A/42
3 Signal EDC17, pin A/61
