42
SECTION 6 - GENERAL MECHANICAL OVERHAUL
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Checking the timing and oil pump gear control
Figure 89
144834
Check that the toothing of the gear is neither damaged nor
worn; if it is, take it out with an appropriate extractor and repla-
ce it.
When fitting the gear (1) on the crankshaft (2), heat it for no
longer than 2 hours in an oven at the temperature indicated
below .
Technical data
Heating temperature for gear fit-
ting
180ËšC
Let it cool down after pressing
If changing the pin (3), after fitting it on, check it protrudes from
the crankshaft as shown in the figure.
