36
SECTION 6 - GENERAL MECHANICAL OVERHAUL
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Main half-bearings selection (rectified pins)
If the journals have been rectified, the procedure described cannot be applied.
In this case, make sure that the new diameters of the pins is as indicated in the table and fit the only type of half-bearing indicated
for the undersizing in question.
210306
-0.127 CLASS
1
106.300
106.307
2
106.308
106.315
3
160.316
106.323
4
106.324
106.330
210307
1
99.843
99.850
Green/Black Yellow/Black* Yellow/Black* Black / Black
Yellow/Black* Yellow/Black* Black / Black Black / Black
2
99.851
99.858
Green/Black Green/Black Yellow/Black* Yellow/Black*
Green/Black Yellow/Black* Yellow/Black* Black / Black
3
99.859
99.866
Red / Black Green/Black Green/Black Yellow/Black*
Green/Black Green/Black Yellow/Black* Yellow/Black*
4
99.867
99.873
Red / Black Red / Black Green/Black Green/Black
Red / Black Green/Black Green/Black Yellow/Black*
* Not supplied as a spare part. If necessary, replace with Green half-bearing
NOTE If using main half-bearings of a different thickness, fit the thicker bearings at the bottom (plate side).
