8
SECTION 6 - GENERAL MECHANICAL OVERHAUL
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Fitting the engine on the rotating stand
NOTE Position a suitable container below the sump to
collecttheoilasitdrainsoutofthedrainplug.
Drain the engine oil by removing the plug from the oil sump.
Ref.
No. Description
(-) 1 Plug M22 X 1.5
The engine oil is highly pollutant and noxious.
In case of contact with skin, wash thoroughly with
water and detergent.
Suitably protect skin and eyes; proceed in
accordance with accident prevention standards.
Suitably dispose of the residuals and in accordance
with regulations.
Figure 10
223409
Secure the engine to the rotating stand 99322230 with the brackets 99361036 (1).
