FPT CURSOR Series - Big End Half-Bearings Selection

SECTION 6 - GENERAL MECHANICAL OVERHAUL
39
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
Big end half -bearings selection (nominal diameter pins)
210309
210312
STD CLASS
1
100.000
100.010
2
100.011
100.020
3
100.021
100.030
210310
1
95.990
96.000
Red Red Green
Red Green Green
2
95.980
95.989
Red Green Green
Green Green Yellow*
3
95.970
95.979
Green Green Yellow*
Green Yellow* Yellow*
* Not supplied as a spare part. If necessary, replace with Green half-bearing
NOTE If using big end half-bearings of a different thickness, fit the thicker bearing at the bottom.
