FPT CURSOR Series - Defining the Diameter Class of the Seats for Half-Bearings on the Crankcase

SECTION 6 - GENERAL MECHANICAL OVERHAUL
29
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
Defining the diameter class of the seats for half-bearings on the crankcase
Figure 80
190208
To identify the diameter class of the seats for the main half-bearings, look at the front part of the crankcase in the position as indicated
in the figure.
