FPT CURSOR Series User Manual

SECTION 3 - ELECTRIC EQUIPMENT
1
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
SECTION 3
Electrical equipment
Page
MAIN COMPONENTS 3...................
ENGINE SIDE WIRING 4...................
- Engine side wiring diagram 4................
- Engine side wiring diagram 5................
PIN OUT CONNECTOR 1A (96 PIN) -
CONTROL UNIT EDC 17 HP 41 6.........
CRIN INJECTOR 3.3 9......................
- Rail pressure sensor (RSD 4) 9..............
- Pressure sensor inside engine crankcase 10.....
- Crankshaft sensor 11......................
- Camshaft sensor 12.......................
- Fuel temperature sensor 13.................
- Coolant temperature sensor 13..............
- Oil pressure and temperature sensor 14.......
- Turbocharging air pressure and temperature sensor 14
- Fuel filter clogged sensor 15.................
ALTERNATOR 16..........................
VELECTRIC STARTER MOTOR 17.............
- Electric starter motor wiring diagrams 18.......

FPT CURSOR Series Specifications

General

Engine Type	Diesel
Configuration	Inline
Aspiration	Turbocharged
Fuel System	Common Rail
Cooling System	Liquid Cooled
