FPT CURSOR Series User Manual

12
SECTION 7 - TECHNICAL SPECIFICATIONS
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
DETAIL
TORQUE
Nm kgm
Camshaft gear fastening screws (*) M14x4x60
1
st
Phase pre-tightening 60 ± 3 6±0,3
2
nd
PhaseTightening to angle 60˚
Screw fixing pulser ring to timing gear
M8x1.25 24.5 ± 2.5 2.5 ± 0.2
Exhaust manifold fastening screws (**)L M10x1.5x70
1
st
Phase pre-tightening 30 ± 5 3±0.5
2
nd
Phase tightening 60 ± 5 6 ± 0.5
Screws fastening connecting rod cap
M14x2
1
st
Phase pre-tightening 70 7
2
nd
Phase Tightening to angle 60˚
Screws fixing engine flywheel (*)L
M18x1.5x72
1
st
Phase pre-tightening 120 ± 6 12 ± 0,6
2
nd
Phase Tightening to angle 90˚
Screws fixing the damper flywheel to the
drive pulley (*)
M14x2
1
st
Phase pre-tightening 70 7
2
nd
Phase Tightening to angle 50˚
Screws securing guide pulley to crankshaft (*)
M14x2
1
st
Phase pre-tightening 70 7
2
nd
Phase Tightening to angle 50˚
Fixing screw of transmission gear pin (*)
M12x1.75x110
1
st
Phase pre-tightening 30 ± 1.5 3±0,15
2
nd
Phase Tightening to angle 90˚
Screw fixing link rod for idle gear
M8x1.25x16 24.5 ± 2.5 2.4 ± 0.25
Double gear fastening screws M12x1.75x90
1
st
Phase 30 ± 1.5 3±0,15
2
nd
Phase 90˚
Screws fixing the oil pump
M8x1,25x35 / 70 25 ± 2.5 2.5 ± 0.2
Screw fixing crankshaft gasket front cover M8x1.25x16 25 ± 2.5 2.5 ± 0.2
Diesel filter breather 17.5 ± 2.5 1.75 ± 0.25
Screw fastening fuel filter support M8x1.25 24.5 ± 2.5 2.4 ± 0.2
Fuel filter cap 32.5 ± 2.5 3.2 ± 0.2
Fuel filter drain 1.5 ± 0.5 0.2 ± 0.1
Screw fastening oil filter support M8x1.25x65 24.5 ± 2.5 2.45 ± 0.2
Oil filter cap 60 ± 5 6±0.5
Oil filter drain plug 6.5 ± 1.5 0.7 ± 0.1
ECU mount retaining screws M8x1.25x16 24.5 ± 2.5 2.45 ± 0.25
Control unit protection bracket M6x1x25 8±2 0.8 ± 0.2
Fuel pipe from tank to control unit support
bracket screws
M8x1.25x16 24.5 ± 2.5 2.45 ± 0.25
Screws and nuts securing turbocharger M12x1.75 75 7.5
Oil deliver pipe to turbocharger M8x1.25 Screws 24.5 ± 2.5 2.45 ± 0.25
Oil deliver pipe to turbocharger M16 UNION 42.5 ± 2.5 4.25 ± 0.25
Screws fastening turbocharger oil deliver pipe
to crankcase
M10 10 ± 1 1±0.1
Screws fastening oil return pipe to
turbocharger
M8x1.25 24.5 ± 2.5 2.4 ± 0.2
Screws securing thermostat assemblyL M8x1,25x50 / 100 30 ± 3 3±0.3
Cylinder head degas pipe M10x1.5 25 ± 2.5 2.5 ± 0.25

FPT CURSOR Series Specifications

General

Engine Type	Diesel
Configuration	Inline
Aspiration	Turbocharged
Fuel System	Common Rail
Cooling System	Liquid Cooled
