14
SECTION 7 - TECHNICAL SPECIFICATIONS
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
DETAIL
TORQUE
Nm kgm
Screws securing Blow-by filterkL M6x1x40
1
st
Phase pre-tightening 5 0.5
2
nd
Phase tightening 15 ± 1.5 1.5 ± 0.15
Fastening screws for blow-by cover
M6x1x25 7±1 0.7 ± 0.1
Screws fastening alternator support M10x1.5 44 ± 4 4.4 ± 0.4
Alternator fixing screws
M10x1.5 44 ± 4 4.4 ± 0.4
M8x1.25 24.5 ± 2.5 2.45 ± 0.25
Screws fastening hydraulic pump compartment
cover to distribution housing
M8x1.25x20 20.5 ± 2.5 2.05 ± 0.25
Rev sensor fastening screw M6x12 8±2 0.8 ± 0.2
Timing sensor fastening screw M6x12 8±2 0.8 ± 0.2
Securing rail pressure sensor M18x1.5 70 ± 5 7±0.5
Rail overpressure safety valve M20x1.5 110 ± 5 11 ± 0.5
Water temperature sensor retainer screws M12x1.5 20 ± 5 2±0.5
Air pressure and temperature fastening screws M6 11.5 1.15
Fuel pressure and temperature fastening
screws
M6 8±2 0.8 ± 0.2
Oil pressure and temperature fastening screws M6 11.5 1.15
Screws fastening oil pressure regulating valve M8x1.25x20 25.5 ± 2.5 2.55 ± 0.2
Pressure sensor retainer on the rocker cover M10x1
27.25 ±
2.75
2.7 ± 0.28
Nuts for injector electrical connection M4 1.5 ± 0.25 0.15
Head wiring connector fixing screw 8±2 0.8 ± 0.2
Fan grille fastening screws M8x1.25x20 18 ± 4 1.8 ± 0.4
Fastening screw for radiator assembly tie brac-
ket
M10 37.5 ± 7.5 3.75 ± 0.75
Fastening screw for radiator assembly to sup-
port bracket.
M10 37.5 ± 7.5 3.75 ± 0.75
Fan fastening screws M8x1.25 21.5 ± 4.5 2.15 ± 0.45
Airfiltermountfasteningscrews
M8
M6
M10
M18
18 ± 4
8±2
37.5 ± 7.5
245 ± 50
1.8 ± 0.4
0.8 ± 0.2
3.75 ± 0.75
24.5 ± 5
Fastening screw for radiator assembly support
bracket.
M12x1.75 69 ± 14 6.9 ± 1.4
Screws fixing combustion air intake pipe to tur-
bocharger
M8 18 ± 4 1.8 ± 0.4
* Lubricate with engine oil before assembly
** Lubricate with graphitised oil before assembly
k Apply LOCTITE 243 before assembly
L See tightening sequence
