SECTION 3 - ELECTRIC EQUIPMENT
7
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
Pin Signal
A37 Air pressure temperature sensor sign al
A38 -
A39 Coolant temperature sen sor signal
A40 -
A41 -
A42 Crankshaft pressure sensor ground
A43 -
A44 -
A45 -
A46 -
A47 -
A48 -
A49 Cylinder 1 injector
A50 Cylinder 2 injector
A51 Cylinder 3 injector
A52 -
A53 -
A54 -
A55 -
A56 -
A57 -
A58 ZME Fuel metering unit power supply
A59 Common ground (fu el temperature sensor, coolant temperature sensor)
A60 Rail pressure sensor ground
A61 Crankshaft pressure sensor signal
A62 Fuel pre-filter clogged sensor signal
A63 -
A64 -
A65 Crankshaft sensor sign al (-)
A66 Crankshaft sensor signal (+)
A67 Camshaft sensor signal (+)
A68 Camshaft sensor signal (-)
A69 Common ground (input 7)
A70 -
A71 -
A72 -
A73 Cylinder 1 injector
A74 Cylinder 2 injector
A75 Cylinder 3 injector
A76 -
A77 -
A78 Fuel filter clogged sensor ground
A79 Fuel filter clogged sensor signal
A80 -
A81 -
A82 -
A83 ZME Fuel metering unit
