Notes to service personnel
Be sure to read this manual carefully to gain a thorough understanding of the correct procedures before servicing this product.
The printer processor uses tapping truss head screws, spike truss head screws and Washer head screws (for ground). When
attaching the screws once removed, make sure they are on their original positions. These screws are used for the place where
grounding is required.
Tapping truss head screw
Spike truss head screw (green)
Washer head screw (for ground)
SCREW
System program:
• QSS-3701/3702(S)/3703/3704/3705: Ver.5
• 7500/7600/7700/7900: Ver.2
! It is prohibited to show, provide, lend or transfer this manual to others except the service personnel.
! The contents of this manual are subject to change without notice.
! Illustrations in this manual may vary depending on the model or manufacturing lot.
