Frontier LP7700 - Output Check (Processor) [F

Maintenance
1/7
3. Mode
35320
35320
Output Check (Processor) [F]
Description for each specification
For the specifications other than [F] specification, this section only gives description that differs from that for [F] specification. See below
for the description for each specification.
!
!!
! Output Check
!
!!
! 1 (for each specification)
!
!!
! 2 (for each specification)
*2
*1. If one of the waste solution float switches is ON, the replenishment pump does not work.
*2. SP1: The menus marked with (SP1) in the table below are only shown when the service personnel password (2260) has been entered.
Reference
☞Output Check (Processor) [N] ☞Output Check (Processor) [SM] ☞Output Check (Processor) [J]
Item Specification Reference
Processor Section F ☞1 (for each
specification)
☞2 (for each
specification)
*2
☞3 (for each specification)
*6
N ☞ 1 [N] ☞2 [N]
SM ☞1 [SM] ☞2 [SM] ☞3 [SM]
J
☞Processor Section
1[J]
☞Processor Section 2[J] ☞Tablet
Replenishment
Section 1[J]
☞Tablet
Replenishment
Section 2[J]
Dryer Section Common
☞Dryer Section (common to all specifications)
Order
Classification
Section
☞Order Classification Section (common to all specifications)
Colorimeter Unit ☞Colorimeter Unit (common to all specifications)
No. Display Status
1 Drive Motor + Drive Cooling Fan Press Execute to start, and Cancel to stop.
2 P1 Heater
3 P2 Heater
4 PS Heater
5 P1 Cooling Water Solenoid Valve
6 P2 Cooling Water Solenoid Valve
7 PS Cooling Water Solenoid Valve
8 Tank Cooling Fan
9Exhaust Fan
10 Processor Condition Lamp (Green) Press Execute to turn on, and Cancel to turn off.
11 Processor Condition Lamp (Red)
12 Signal Lamp Press Execute to turn on, and Cancel to turn off.
13 Control Strip Advance Motor • Execute: Control Strip Advance Motor starts.
• Cancel: Control Strip Advance Motor does not stop.
No. Display Status
1 Replenisher Cartridge Open Motor See
☞Replenisher Cartridge Open Motor operation.
2 P1R Replenisher Pump Press Execute moves each replenishment pump one stroke
(maximum).
*1
IMPORTANT
• If each replenishment pump is operated, the initial value
is used for the next opening.
3 P2RA Replenisher Pump
4 P2RB Replenisher Pump
5 PSR Replenisher Pump
