Service personnel tool list
1/1
8. Appendix
80310
80310
Serv ic e personnel t ool list
Service personnel tool list
NOTE
• For details about service personnel tools related to film carrier like scanner adjustment chart, refer to the Scanner Service Manual.
(Printer section)
(Processor section)
Tool Part No. Explanation
Head adjusting jig A050486-01 Used to adjust the CVP printing pressure.
Optical fiber cable pushing bar A073143-01 Used to pull out the optical fiber cable.
For details about how to use the optical fiber cable pushing bar, see
☞How to use the optical fiber cable pushing bar in 68100
Loupe H099047-00 Used to adjust the exposure position.
Fiber cutter L003100-00 Used to cut the end of ARCNET cable when it is abnormal.
For details about how to use the fiber cutter, refer to 68100
☞How
to use the fiber cutter.
Aspirator H103007-00 To suck out the dust in the connector on the PCB connected to the
ARCNET cable.
For details about how to use the aspirator, refer to
☞How to use
the aspirator in 68100.
Tool Part No. Explanation
Colorimeter height adjustment jig A076430-01 Used to adjust the height of measuring point of the colorimeter.
Grounding resistance measurement cable unit W407756-01 Used to check the grounding resistance between input section and
printer section or processor section.
Air exhaust tool (pipe type) assembly A050400-01 Used when installing the SM specification and replacing the
replenisher pump. (compatible with the conventional SM systems)
Probe replacing jig A053235-01 Used when replacing the probe. (compatible with the conventional
SM systems)
Hose H121232 Use this to operate each automated flushing valve and auto cleaning
pump in Output Check. (only F)
