Frontier LP7700 - No. 00507 Close the Processor Top Cover

4. Troubleshooting
40500
7/12
40500
Attention message: Processor
No. 00507
Close the Processor Top Cover.
Attention message release
YES or automatic release
• The attention message will be automatically closed when the processor top cover is closed.
Condition
NOTE
• The drive motor, the refilling water pump, the cleaning pump, and the exhaust fan will stop when the interlock switch (processor top
cover) turns off.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 While prints are not being made, the interlock switch (processor top cover) turns off.
When auto cleaning is to be carried out, the interlock switch (processor top cover) turns off.
When refilling with water is to be carried out, the interlock switch (processor top cover) turns off.
1 Check that the processor top cover is securely closed.
Adjustment failure point Manual No.
Interlock switch (Processor top cover)
☞63290
Failed part Manual No.
Interlock switch (Processor top cover) ☞63290
Processor relay PCB
☞66220
Processor control PCB ☞66200
Symptoms due to the wiring connection failure Symptoms of fuse blowout
−
☞4203 −
