4. Troubleshooting
46100
5/33
46100
Error message: Printer 2
No. 06112
Could not load the paper. Paper Magazine C
Error message release
YES
Condition
NOTE
• For details about magazine initial operation, see 55100 ☞Performs magazine initial operation.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even though a specified length of paper is advanced after paper loading started, paper end sensor C does not
detect DARK during setup or printing for mechanical adjustments.
00002 Even when a specified length of paper is advanced after the paper end sensor C has turned DARK, the loading
sensor does not turn DARK.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
Advance failure Manual No.
Paper magazine motor C
☞63051
Paper supply motor B/C ☞63060
Printer I/O PCB 2 ☞66030
Printer I/O PCB 1
☞66020
Printer control PCB ☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor C
☞63051
Printer I/O PCB 3 ☞66040
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor
☞66030
Printer I/O PCB 2 ☞66030
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
