12/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06140
Lane Select Motor (Left) operation error.
No. 06141
Lane Select Motor (Right) operation error.
Error message release
NO
Condition
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The lane select sensor (left) or (right) does not turn DARK even though the lane select motor (left) or (right) has
operated for a specified pulse.
00002 The lane select sensor (left) or (right) does not turn LIGHT even though the lane select motor (left) or (right) has
operated for a specified pulse.
Operation failure Manual No.
Lane select motor (right, left) ☞63100
Printer I/O PCB 3
☞66040
Printer I/O PCB 1 ☞66020
Printer control PCB ☞66000
Detection failure Manual No.
Lane select sensor (right or left) ☞63100
Printer I/O PCB 3 ☞66040
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
