Frontier LP7700 - No. 06199 Pressure Release Motor A2 Operation Error

30/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06199
Pressure Release Motor A2 operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The pressure change sensor A2 does not turn DARK even though a specified time elapsed after activating the
pressure release motor A2.
00002 The pressure change sensor A2 does not turn LIGHT even though a specified time elapsed after activating the
pressure release motor A2.
1 Check that the paper supply unit A2 is installed correctly.
Operation failure Manual No.
Pressure release motor A2 ☞63051
Quad magazine PCB ☞66055
Printer control PCB
☞66000
Detection failure Manual No.
Pressure change sensor A2 ☞63051
Quad magazine PCB
☞66055
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
