Frontier LP7700 - Order Specifying Led Pcb 3 (J)

Explanation of PCBs (Processor section)
1/2
6. Electrical parts
66860
66860
Order specifying LED PCB 3 (J391426)
!
!!
! Function
• Indication of prioritized order from the second rack through the ninth rack
• Indication of split order from the second rack through the ninth rack
NOTE
• The order specifying LED PCB 3 is only for the print sorter unit (6-inch type/17 orders).
!
!!
! Reference
!
!!
! Adjustments and precautions for PCB replacement
• None
!
!!
! Unused connector
• None
Layout diagram Symptom due to the poor connection of
wiring
Symptoms of fuse blowout
☞63271 - -
P868P869
LED6
LED5
LED4
LED3
LED2
LED1
LED66
LED65
LED64
LED63
LED62
LED61
LED12
LED11
LED10
LED9
LED8
LED7
LED72
LED71
LED70
LED69
LED68
LED67
LED18
LED17
LED16
LED15
LED14
LED13
LED78
LED77
LED76
LED75
LED74
LED73
LED24
LED23
LED22
LED21
LED20
LED19
LED84
LED83
LED82
LED81
LED80
LED79
LED30
LED29
LED28
LED27
LED26
LED25
LED90
LED89
LED88
LED87
LED86
LED85
LED36
LED35
LED34
LED33
LED32
LED31
LED96
LED95
LED94
LED93
LED92
LED91
LED42
LED41
LED40
LED39
LED38
LED37
LED48
LED47
LED46
LED45
LED44
LED43
LED54
LED53
LED52
LED51
LED50
LED49
LED60
LED59
LED58
LED57
LED56
LED55
Front
Back
G085076
