Frontier LP7700 - No. 06211 Paper Remains in the Exposure Advance Unit

4. Troubleshooting
46200
10/21
46200
Error message: Printer 3
No. 06211
Paper remains in the Exposure Advance Unit.
Error message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 After the initial operation, after turning on the system, after releasing the error of paper jam, or after opening or
closing the printer door, the status of exposure start sensor was DARK.
1 Confirm whether the paper remains at exposure start sensor in the printer.
2 Check that the exposure start sensor is not soiled.
3 Carry out Paper Sensor LED Light Intensity Adjustment in Functions of Paper Sensor Adjustment.
☞36000
Detection failure Manual No.
Exposure start sensor ☞63070
Printer I/O PCB 3
☞66040
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
