4. Troubleshooting
46200
46200
Error message: Printer 3
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Detection failure (triple magazine) Manual No.
Paper end sensor A
☞63051
Triple magazine PCB ☞66050
Printer control PCB ☞66000
Printer I/O PCB 1
☞66020
Detection failure (quad magazine) Manual No.
Paper end sensor A Paper end sensor A2 ☞63051
Quad magazine PCB
☞66055
Printer control PCB ☞66000
Printer I/O PCB 1 ☞66020
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
