Frontier LP7700 - Input Check (Printer)

Maintenance
1/5
3. Mode
35210
35210
Input Check (Printer)
Bringing up the display
Maintenance → Extension → Maintenance → Input Check → Printer
!
!!
! Input Check
!
!!
! Explanation
A buzzer will sound if the sensor, limit switch or any other device that is currently selected detects DARK or ON.
IMPORTANT
• The momentary operation cannot be displayed on the input check display because there is a time lag of approx. 0.5
seconds.
!
!!
! Paper Supply 1
!
!!
! Paper Supply 2
!
!!
! Magazine Code B
Item Reference
Paper Supply Unit
☞Paper Supply 1 ☞Paper Supply 2
☞Magazine Code B ☞Magazine Code C
☞Magazine Unit A ☞Magazine Unit A2-1
☞Magazine Unit A2-2
Exposure Advance Unit
☞Exposure Advance Unit
Exposure Engine Section ☞Exposure Engine Section
Paper Advance Section
☞Paper Advance Section 1 ☞Paper Advance Section 2
Others
☞Operation of the interlock switches
No. Display Status
1 DARK/LIGHT Paper End Sensor B DARK Paper is detected.
2 DARK/LIGHT Paper End Sensor C DARK Paper is detected.
3 DARK/LIGHT Paper Loading Sensor DARK Paper is detected.
4 DARK/LIGHT Cut Home Sensor DARK Home position: When the cutter is opened.
5 DARK/LIGHT Cut End Sensor DARK When the cutter is closed.
6 DARK/LIGHT Paper Hold Sensor DARK When the pressure is applied on the paper.
7 DARK/LIGHT Zigzagging Correction Sensor (Left) DARK When the left arm is detected.
8 DARK/LIGHT Zigzagging Correction Sensor (Right) DARK When the right arm is detected.
9 DARK/LIGHT Paper Supply Pressure Change Sensor DARK When the pressure is applied on the paper.
10 ON/OFF Interlock Switch (Printer Top Cover) See
☞Operation of the interlock switches.
11 ON/OFF Interlock Switch (Printer Doors 1, 4)
12 ON/OFF Interlock Switch (Printer Door 2)
13 ON/OFF Printer Door 3 Sensor
No. Display Status
1 ON/OFF DIP Switch 1-1 OFF Displays the dip switch status of the printer control
PCB.
☞66000
Turn off all.
2 ON/OFF DIP Switch 1-2 OFF
3 ON/OFF DIP Switch 1-3 OFF
4 ON/OFF DIP Switch 1-4 OFF
No. Display Status
1 DARK/LIGHT Paper Magazine Code Sensor B1 (Right) DARK When the pin is detected.
