4/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06107
R Laser temperature is out of range.
Error message release
NO
Condition
NOTE
• The R laser thermosensor is built into the R laser.
• You can check the temperatures of R laser in Input Check.
☞35210
• Temperature of the laser unit heater, B laser heater and R laser heater is adjusted at the same time.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 R laser temperature is controlled between 46.7°C and 47.3°C for 6 seconds or more (standby status) and then the
temperature exceeds 50.0°C (upper limit temperature) again.
00002 R laser temperature is controlled between 46.7°C and 47.3°C for 6 seconds or more (standby status) and then the
temperature falls under 44.0°C (lower limit temperature) again.
1 See 4302
☞If the temperature of R laser thermosensor is not within the range from 46.7°C to 47.3°C.
Failed part Manual No.
Laser control PCB ☞66010
Laser unit
☞63080
Laser unit heater ☞63080
Laser unit cooling fans 1 or 2 (Suffix number 00001) ☞63050
