3/15
4. Troubleshooting
46000
46000
Error message: Printer 1
No. 06014
Paper did not rewind. Paper Magazine A
No. 06015
Paper did not rewind. Paper Magazine B
Error message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Error message No. Condition
No. 06014 Paper cannot be rewound into paper magazine A.
No. 06015 Paper cannot be rewound into paper magazine B.
Suffix number Condition
00001 Even when a specified length of paper is rewound after the paper rewinding has started, the paper loading sensor
does not turn light.
00002 Even when a specified length of paper is rewound after the paper loading sensor has turned light, paper end
sensors A and B do not turn LIGHT.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
3 Check that the paper loading sensor and the paper end sensor are not soiled.
Advance failure Manual No.
Paper magazine motor A or B ☞63051
Paper supply motor A, B or C ☞63060
Printer I/O PCB 2
☞66030
Printer I/O PCB 1
☞66020
Triple magazine PCB
☞66050
Printer control PCB
☞66000
Detection failure (paper end sensor) Manual No.
Paper end sensor A or B ☞63051
Printer I/O PCB 3
☞66040
Triple magazine PCB ☞66050
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor ☞66030
Printer I/O PCB 2 ☞66030
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
