4. Troubleshooting
46000
4/15
46000
Error message: Printer 1
No. 06016
Paper Cutter operation error.
Error message release
NO
Condition
IMPORTANT
• If the paper supply unit is not set correctly, this error may occur.
NOTE
• The cutter blade may be locked or seized.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The cut home sensor does not detect LIGHT even though a specified time has passed after the cut operation
started.
00002 The cut end sensor does not turn DARK even though a specified time has passed after the cut operation started
and the cut home sensor turned light.
00003 Even when a specified time has passed after the cut operation was completed, the cut end sensor does not turn
LIGHT.
00004 Even when a specified time has passed after the cut operation was completed and the cut end sensor turned
LIGHT, the cut home sensor does not turn DARK.
00005 The cut home sensor and cut end sensor are DARK in the initial operation.
1 Confirm that the paper supply unit is installed correctly.
Blown fuses Manual No.
F32 Printer I/O PCB 1 ☞66020
Operation failure Manual No.
Cutter unit
☞25620
Cut motor
☞63060
Printer I/O PCB 2 ☞66030
Printer I/O PCB 1
☞66020
Printer control PCB
☞66000
Detection failure Manual No.
Cut home sensor
☞63060
Cut end sensor
Printer I/O PCB 2 ☞66030
Printer I/O PCB 1
☞66020
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
