Frontier LP7700 - No. 01556 the Colorimeter Unit Is Not Set

4. Troubleshooting
41550
3/3
41550
Attention message: Colorimeter
No. 01556
The Colorimeter Unit is not set.
Attention message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 The colorimeter unit is not detected while it does not operate or communicate.
1 Confirm that the colorimeter unit is correctly attached.
Failed part Manual No.
Processor control PCB ☞66200
Processor I/O PCB 2 ☞66211
Colorimeter unit
☞27460
Symptoms due to the wiring connection failure Symptoms of fuse blowout
− ☞4203 −
