Frontier LP7700 - No. 05600[J] Tablet Drum Operation Error. CD; No. 05601[J] Tablet Drum Operation Error. Bf

Error message: Tablet replenishment
1/5
4. Troubleshooting
45600
45600
Error message: Table t replen ishment
No. 05600[J]
Tablet Drum operation error. CD
No. 05601[J]
Tablet Drum operation error. BF
No. 05602[J]
Tablet Drum operation error. STB
Error message release
YES
Condition
NOTE
• The home position is the position when tablet sensors 1 and 2 are LIGHT.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix
number
Condition
00000 Even though the drum was moved for a specified time to return it to the home position, the home position was not detected.
Even though the system attempted to move the drum for a specified time to exit the home position, the drum remained at that
position.
Even though the drum is reversed, tablet sensor 1 does not turn DARK after a specified time.
Even though a specified time has passed since tablet sensor 1 passed the home position and turned DARK, tablet sensor 1
does not turn LIGHT.
1 Check if the chute is not dirty.
2 Check if the bucket platform is not dirty.
3 Check if the tablet is not stuck between the cartridge and drum.
Uncleaned places Manual No.
The module drum is cleaned. ☞27690
Adjustment failure point Manual No.
Upper, middle and lower elevator sensors attaching position adjustment failure ☞63310
Failed part Manual No.
Check if the elevator does not tilt. -
Confirm that tablet sensor is not dirty.
☞63310
Tablet sensors 1 and 2 ☞63310
Drum Motor CD, BF, STB
☞63310
• If the drum motor is not activated when 24 V DC is output between PINs 15 and 16 of the drum motor connectors, the motor is
defective.
Tablet replenishment driver PCB
☞66500
Processor control PCB
☞66200
