Frontier LP7700 - No. 06208 Paper Has Jammed in the Paper Supply Unit

4. Troubleshooting
46200
6/21
46200
Error message: Printer 3
No. 06208
Paper has jammed in the Paper Supply Unit.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The exposure start sensor does not turn DARK even though the paper was fed to the exposure standby position.
1 Check that the exposure start sensor is not soiled.
2 Carry out Paper Sensor LED Light Intensity Adjustment in Functions of Paper Sensor Adjustment.
☞36000
Operation failure Manual No.
Exposure advance motor 1
☞63090
Exposure advance motor 2 ☞63100
Printer I/O PCB 3 ☞ 66040
Printer control PCB
☞66000
Detection failure Manual No.
Exposure start sensor ☞63070
Printer I/O PCB 3
☞66040
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
