2/5
4. Troubleshooting
45600
45600
Error message: Tablet replenishment
No. 05603[J]
A tablet has jammed.
No. 05604[J]
A tablet has jammed. BF
No. 05605[J]
A tablet has jammed.
Error message release
YES
Condition
NOTE
• The home position is the position when tablet sensors 1 and 2 are LIGHT.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 Even though a specified time has passed since the drum was moved from the home position and tablet sensor 1 turned
DARK, tablet sensor 1 does not turn LIGHT.
Even though the drum was moved from the home position, tablet sensor 1 does not turn DARK after a specified time.
Even though a specified time has passed since tablet sensor 1 passed the home position, it does not turn DARK.
Even though the drum is reversed, the home position is not detected after a specified time.
1 Check if the chute is not dirty.
2 Check if the bucket platform is not dirty.
3 Check if the elevator does not tilt.
4 Check if the tablet is not stuck between the cartridge and drum.
Uncleaned places Manual No.
The module drum is cleaned.
☞27690
Adjustment failure point Manual No.
Upper, middle and lower elevator sensors attaching position adjustment failure
☞63310
Failed part Manual No.
Check if the elevator does not tilt. -
Confirm that tablet sensor is not dirty. ☞63310
Tablet sensors 1 and 2
☞63310
Drum Motor CD, BF, STB ☞63310
Tablet replenishment driver PCB ☞66500
Processor control PCB
☞66200
