3. Mode
35320
4/7
35320
Maintenance
Output Check (Processor) [N]
Description for each specification
For the specifications other than [N] specification, this section only gives description that differs from that for [N] specification. See below
for the description for each specification.
!
!!
! Explanation
Check the operation of the motor, buzzer or LED that is currently selected.
!
!!
! 1 [N]
!
!!
! 2 [N]
Reference
☞Output Check (Processor) [SM] ☞Output Check (Processor) [J] ☞Output Check (Processor) [F]
No. Display Status
1 Drive Motor + Drive Cooling Fan Press Execute to start, and Cancel to stop.
2 CD Heater
3 BF Heater
4 STB Heater
5 CD Cooling Water Solenoid Valve
6 BF Cooling Water Solenoid Valve
7 STB Cooling Water Solenoid Valve
8CD Replenisher Pump
9BF Replenisher Pump
10 STB Replenisher Pump
11 Tank Cooling Fan
12 Exhaust Fan
13 Processor Condition Lamp (Green) Press Execute to turn on, and Cancel to turn off.
14 Processor Condition Lamp (Red)
15 Signal Lamp
16 Control Strip Advance Motor • Execute: Control Strip Advance Motor starts.
• Cancel: Control Strip Advance Motor does not stop.
No. Display Status
1 CD Replenisher Pump Press Execute to start, and Cancel to stop.
2BF Replenisher Pump
3 STB Replenisher Pump
4 CD-W Refilling Water Pump
5 BF-W Refilling Water Pump
6 STB 1-W Refilling Water Pump
7 STB 2-W Refilling Water Pump
8 STB 3-W Refilling Water Pump
9 STB 4-W Refilling Water Pump
10 Cleaning Pump
