4. Troubleshooting
45530
45530
Error: Processor 2
No. 05552
Dryer Lane Select Guide operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix
number
Condition
00004 When Dryer selection solenoid 1 is moved to the colorimeter side for automatic colorimetry, the test print is not fed to the
colorimeter but output to the print conveyor unit (Print Sensor (Left), Print Sensor (Center) and Print Sensor (Right) of
the dryer rack detect DARK.)
00005 When Dryer selection solenoid 1 is moved to the colorimeter side for automatic colorimetry, the test print is not fed to the
colorimeter but output to the print receiving tray (large).
1 Check whether Dryer selection solenoid 1 and Dryer selection solenoid 2 normally operate.
☞35320
2 Confirm that the paper guide of the dryer rack is correctly attached.
3 Clean the dryer lane select sensor with the blower brush, etc.
4 Carry out Print Sensor LED Light Intensity Adjustment in Functions of Print Sensor Adjustment.
See
☞33001.
Failed part Manual No.
Dryer lane select sensor ☞63260
Dryer selection solenoid 1/Dryer selection solenoid 2 ☞63260
Processor control PCB
☞66200
Processor I/O PCB 1 ☞66210
Symptoms due to the wiring connection failure Symptoms of fuse blowout
−
☞4203 ☞4252
