Frontier LP7700 - No. 06135 Arm Unit 1 Operation Error

8/33
4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06135
Arm Unit 1 operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The zigzagging correction sensor does not turn DARK even though the paper supply arm motor moved arm unit
1 for the specified length in the direction of paper advance.
00002 The zigzagging correction sensor does not turn LIGHT even though the paper supply arm motor moved arm unit
1 for the specified length in the reverse direction of paper advance when zigzag correction sensor is DARK.
1 Clean each sensor using a blower brush.
2 Carry out Paper Sensor Adjustment.
☞36000
Operation failure Manual No.
Paper supply arm motor (right or left) ☞63060
Printer I/O PCB 2
☞66030
Printer I/O PCB 1 ☞66020
Printer control PCB ☞66000
Detection failure Manual No.
Zigzagging correction sensor (right or left) ☞63070
Printer I/O PCB 3 ☞66040
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
