4. Troubleshooting
46100
3/33
46100
Error message: Printer 2
No. 06106
G Laser light source status error.
Error message release
NO
Condition
NOTE
• The error No.06106 G Laser light source status error. shows that the LDs (laser diodes) built in the G laser head are deteriorated.
If this error No.06106 G Laser light source status error. occurs, past experience has shown that there is a high probability that the
laser unit is the cause.
If the error occurs every day although it used to occur at a few days intervals at first and comes to occur with more increased frequency
so that it cannot be released, the laser unit must be replaced urgently.
• When the error is closed once, the error does not recur until the power supply is reset or the system is started by the program timer.
IMPORTANT
• Check G Laser Light Source Status of Input Check → Printer → Exposure Engine Section, and if it is OK, it is highly
possible that each part at the Failed parts is normal.
☞35210
• Follow the diagnostic procedure shown below if G Laser Light Source Status is No Good.
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 An error occurs in the light source state of G laser.
• For the diagnosis of the laser unit, perform Laser Self-Diagnostic. See ☞35950.
Point
The errors described above occur at the system startup if a connection failure exists between the G laser driver (J/P1665) ↔ laser power
supply (J/P418).
Failed part Manual No.
Laser unit
☞63080
G laser driver ☞66070
Laser control PCB
☞66010
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
