Frontier LP7700 - No. 06224 Paper Remains in the Processor Loading Unit

17/21
4. Troubleshooting
46200
46200
Error message: Printer 3
No. 06224
Paper remains in the Processor loading unit.
Error message release
YES
Condition
NOTE
• The suffix number differs depending on the operation which is currently processed.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Condition
- After the initial operation, after turning on the system, after releasing the error of paper jam, or after opening or closing the
printer door, the status of each sensor was DARK.
Suffix number Condition
00001 Paper sensor 2 (left)
00002 Paper sensor 2 (center)
00003 Paper sensor 2 (right)
1 Confirm that each sensor is not dirty.
2 Confirm that the pressure guide of the paper advance unit 2 is correctly attached.
3 Carry out Paper Sensor LED Light Intensity Adjustment in Functions of Paper Sensor Adjustment.
☞36000
Detection failure Manual No.
Paper sensor 2 (left, center or right) ☞63110
Printer I/O PCB 3 ☞66040
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
